Leapton battery module 5.12kWh

The Leapton battery family offers a reliable and flexible energy storage solution for home and commercial systems. Thanks to LFP (LiFePO₄) technology, it has excellent cycle resistance and long life, ensuring safe and efficient operation. The modular design allows for expansion as needed, making it the perfect choice for dynamically changing energy storage needs.

Important features

Safe and reliable:

• LFP battery cells that are thermally stable and cobalt-free.
• 6000 cycle life at 90% DOD.

Flexible scalability:

• Modular design in 5 kWh units.
• Configuration options: 10.2 kWh, 15.3 kWh, 20.4 kWh.

Outstanding efficiency: High charge/discharge efficiency, ensuring optimal utilization of energy storage.

Excellent compatibility: Suitable for single and three-phase systems, hybrid and retrofit installations.

Weatherproof design: IP65 protection class, ensuring indoor and outdoor installation.

Easy installation: A system that can be quickly and easily assembled with stackable, standard modules.

Technical data

Capacity:

• EH-A05-102/102 (1 module): 5.12 kWh nominal energy, 4.6 kWh usable energy.
• EH-A05-102/204 (2 modules): 10.24 kWh nominal energy, 9.2 kWh usable energy.
• EH-A05-102/307 (3 modules): 15.36 kWh nominal energy, 13.8 kWh usable energy.
• EH-A05-102/409 (4 modules): 20.48 kWh nominal energy, 18.4 kWh usable energy.

Nominal voltage: 102.4 V – 409.6 V (depending on module number).

Maximum charging/discharging power: 5.12 – 20.48 kW.

Operating temperature range: Charging: 0 – +50 °C; Discharge: -20 – +50 °C.

Protection: IP65, with natural convection cooling.

Weight: 70 kg per module (1 module).

Dimensions: 875 mm x 560 mm x 195 mm (1 module), increasing size per module.

Advantages

Long-term safety: The durability and high cycle life of LFP cells guarantee reliable operation.

Flexibility: Scalable design provides easy expansion for growing power needs.

Wide applicability: Compatibility with hybrid inverters and various system types.

Weather resistance: IP65 protection, suitable for outdoor use, increases the system's installation options.

Recommendations

The Leapton battery offers a reliable and efficient solution for those looking for a long-term and scalable energy storage system. With modern LFP technology, easy installation and broad compatibility, it is the perfect choice for both residential and commercial systems.
