Solplanet ASW 4000H-S2 Hybrid Inverter 4kW - 1 Phase
Description
Description
The Solplanet ASW H-S2 series is a single-phase hybrid inverter family designed for residential solar systems. Models between 3–6 kW handle not only solar power generation but also battery energy storage and EPS backup output, making them suitable for systems where the later use of stored energy is an important consideration.
The inverters have 2 independent MPP trackers, with 1 string input per tracker. The MPP voltage range is 40–530 V, and the maximum DC input voltage is 550 V. The maximum input current per MPPT is 16 A, so the devices can be matched to various residential solar arrays.
The series operates with a low-voltage, 48 V / 51.2 V nominal battery. The supported battery type is LiFePO4, with a battery voltage range of 40–60 V. The maximum charge and discharge power is 5000 W, and the maximum charge and discharge current is 100 A. This allows a portion of the energy generated during the day to be used later, for example, during evening consumption.
The EPS output serves to supply a separate consumer circuit in case of a power outage. The nominal EPS power is 5000 VA, and the short-term peak power is 7500 VA for 10 seconds. The switching time is a maximum of 10 ms, so designated consumers can receive backup power within a short period.
The IP66-rated housing allows for both indoor and outdoor installation. Natural convection cooling ensures quiet operation, with a typical noise level of 30 dB(A). BMS communication is available via RS485 / CAN connection, meter connection via RS485 interface, and portal connection using a Wi-Fi stick.
Key features summarized:
- Single-phase hybrid inverters for residential systems
- Power range: 3–6 kW
- Management of solar power generation, battery, and EPS output
- 2 independent MPP trackers, 1 string per MPPT
- Maximum PV array power: 5.5–9 kWp
- MPP voltage range: 40–530 V
- Maximum DC input voltage: 550 V
- Maximum input current per MPPT: 16 A
- LiFePO4 battery support
- Battery voltage range: 40–60 V
- Maximum charge and discharge current: 100 A
- EPS output with a switching time of up to 10 ms
- EPS power: 5000 VA, peak power 7500 VA for 10 seconds
- Maximum efficiency: 97.6%, European efficiency: 97%
- IP66 protection, natural cooling, RS485 / CAN / Wi-Fi communication
The Solplanet ASW H-S2 series is suitable for single-phase solar systems where, in addition to grid production, low-voltage battery energy storage and EPS backup output are required.
