SolaX X1-IES-3.7K AIO Hybrid Inverter 3.7kW - 1 Phase (HV)
Description
Description
The SolaX X1-IES series of single-phase, high-voltage hybrid inverters are available with power ratings from 2.5 to 8 kW. Thanks to the AIO design, the inverter and the modular battery system can be installed as a unified, space-saving system.
The devices operate with an 80-480 V LFP battery system, with a maximum charge and discharge current of 50 A. The capacity of one battery module is 5.1 kWh, which can be expanded up to 20.4 kWh with a maximum of four modules.
The inverters support up to 200% PV-side oversizing. The maximum PV input voltage is 600 V, and there are two or three MPPTs available depending on the model.
In the event of a power outage, the EPS output switches over in less than 10 ms. In battery mode, the inverter can provide double its rated power for 10 seconds.
The system supports intelligent load control, wireless energy meter, and microgrid operation. The IP66-rated devices have multiple built-in safety functions and optional AFCI arc fault protection.
Key features
Power range: 2.5–8 kW
Design: single-phase, AIO hybrid system
Battery voltage: 80–480 V
Battery type: LFP
Storage capacity: 5.1–20.4 kWh
Number of battery modules: 1–4 pcs
Charge and discharge current: max. 50 A
Number of MPPTs: 2 or 3 depending on model
PV oversizing: up to 200%
Maximum PV voltage: 600 V
EPS switchover: less than 10 ms
EPS peak power: double power for 10 seconds
Maximum efficiency: 97.6%
Cooling: natural
Protection class: IP66
Protection: AC/DC Type II SPD, optional AFCI
