GoodWe ESA GW8.3-BAT-D-G20 Battery Module - 8.3kWh
Description
Description
The GoodWe GW8.3-BAT-D-G20 is a higher-capacity LFP battery module from the ESA series. The module has a nominal energy content of 8.32 kWh and a usable energy content of 8.0 kWh.
The battery can be used as part of the GoodWe ESA All-in-One energy storage system. According to manufacturer specifications, it can be combined with other ESA battery modules in a single system. A system can be built with up to 12 modules.
In a three-phase ESA system, the operating voltage range is 700–950 V, while in a single-phase system, it is 350–550 V. The maximum input and output power is 8.0 kW, with a peak output power of 12 kW for 10 seconds.
The module has IP66 protection and an integrated heating function. The noise level is a maximum of 29 dB. Communication is via CAN. Installation can be as a floor-standing tower or wall-mounted.
Key features at a glance:
- LFP / LiFePO4 battery module for GoodWe ESA systems
- Nominal energy: 8.32 kWh; usable energy: 8.0 kWh
- Maximum input and output power: 8.0 kW
- Peak output power: 12 kW for 10 seconds
- Three-phase operating voltage range: 700–950 V
- Single-phase operating voltage range: 350–550 V
- Up to 12 modules can be used in one system
- IP66 protection, integrated heating function, maximum 29 dB noise level
- CAN communication, floor-standing or wall-mounted design
The GoodWe GW8.3-BAT-D-G20 battery module can be used for GoodWe ESA energy storage systems, offering higher capacity per module and an expandable system design.
